Description
Protech PM-613 is a universal ceiling mount for projectors up to 13.5kg/29.7bs. Tilting ceiling plate for flat and sloping ceiling application. It offers multidirectional positioning with four adjustable support arms that can fit a wide range of mounting holes. The quick release connector allows the projector to be installed quickly and then easily released for maintenance, without re-alignment. The retractable aluminum column provides height adjustment for your different choices. This projector mount is perfect for use in classrooms, boardrooms, hotels, bars and restaurants or anywhere a projector needs to be mounted.
FEATURES:
●Adjustable Length: for your different choices
●Adjustable Ceiling Plate: for mounting in flat or sloping ceiling
●360° Rotating Joint: for optimal viewing angles
●Swiveling Joint: offers maximum viewing flexibility
●Cable Management: keeps everything organized
●Adjustable Support Arms: fit most projectors with ease
SPECIFICATION:
| Brand: | Protech |
| Type: | Ceiling Mount |
| Material: | Steel,Aluminum |
| Surface Finish: | Powder Coating |
| Color: | Matte Black,Gloss White |
| Dimensions: | 334x334x900mm (13.1″x13.1″x35.4″) |
| Weight Capacity: | 13.5kg (29.7lbs) |
| Mounting Range: | 54~320mm (2.1″~12.6″) |
| Tilt Range: | +15°~-15° |
| Swivel Range: | +15°~-15° |
| Rotation: | 360° |
| Profile: | 545~900mm (21.5″~35.4″) |
| Installation: | Ceiling Mounted |
| Cable Management: | Yes |
| Mounting Hardware: | Yes |
| Instruction Manual Included: | Yes |
Specifications
Additional information
| Weight | 6 lbs |
|---|---|
| Dimensions | 20 × 6 × 4 in |
